Door Prep: Crossbore 2-1/8", Edge bore 1" ,Latch face 1" x2-1/4"
Backset :    2-3/4" standard. 2-3/8" optional.
Door Thickness: Adjustable 1-3/8" -2"
Cylinder :   5-Pin removable core.  Schlage "C " keyway or Kwikset
                   and other options available.
Handing :  Completely reversible
Rosette :   Removable interior and exterior rosette by screw thread.
Face plates: 1" x2-1/4" square corner standard. Round corner and other
                     options available
Strikes :    2-1/4" full lip square corner standard. Round corner and
                     optional "T" available
Bolt :  1/2" throw, Nickel plated .
